Product Datasheet Search Results:
19 Pages, 384 KB, Original- MS3476W14-4PW-LC
- Aero Conesys
- Conn Circular PIN 4 POS Crimp ST Cable Mount 4 Terminal 1 Port
14 Pages, 956 KB, Original- MS3476W14-4PW-LC
- Amphenol Aerospace
- Circular MIL Spec Connector 4P SIZE 14 STRAIGHT PIN PLUG CRIMP
15 Pages, 606 KB, Original- MS3476W14-4PW-LC
- Amphenol
- Conn Circular PIN 4 POS Crimp ST Cable Mount 4 Terminal 1 Port
15 Pages, 606 KB, Original- MS3476W14-4PW-LC
- Amphenol/spectra-strip
- Conn Circular PIN 4 POS Crimp ST Cable Mount 4 Terminal 1 Port
8 Pages, 1454 KB, Original- MS3476W14-4PW-LC
- Deutsch Uk
- Conn Circular PIN 4 POS Crimp ST Cable Mount 4 Terminal 1 Port Automotive
12 Pages, 656 KB, Original- MS3476W14-4PW-LC
- Souriau
- Conn Circular PIN 4 POS Crimp ST Cable Mount 4 Terminal 1 Port
5 Pages, 149 KB, Original- MS3476W14-4PW-LC
- Te Connectivity / Deutsch
- Circular MIL Spec Connector AFD 4C 4#12 Pin Plug LC
Product Details Search Results:
Aero_conesys/MS3476W14-4PW-LC
{"Contact Classification":"4Signal","Strain Relief":"No","Family":"MS3476","Voltage Rating":"850VDC/600VAC","Gender":"PL","Body Orientation":"Straight","Contact Gender":"PIN","Rad Hardened":"No","Product Length (mm)":"36.07(mm)","Mounting Style":"Cable","Number of Ports":"1(Port)","Operating Temp Range":"-55C to 175C","Product Depth (mm)":"Not Required(mm)","Product Diameter (mm)":"30.05(mm)","Termination Method":"Crimp","Product Height (mm)":"Not Required(mm)","Shell Size / Insert Arrangement":"14-4","Numb...
1682 Bytes - 15:37:52, 14 November 2024
Aero-electric.com/MS3476W14-4PW-LC
816 Bytes - 15:37:52, 14 November 2024
Amphenol-aerospace.com/MS3476W14-4PW-LC
{"Current Rating":"23 A","Shell Material":"Aluminum","MIL Type":"MIL-DTL-26482 II","Termination Style":"Crimp","Insert Arrangement":"14-4","Shell Size":"14","Number of Positions":"4 Position","Product Category":"Circular MIL Spec Connector","Brand":"Amphenol Aerospace","Tradename":"26482","Product Type":"Plugs","Shell Plating":"Olive Drab Cadmium","Manufacturer":"Amphenol","Voltage Rating":"600 V","Wire Gauge":"14-12","Mating Style":"Bayonet","Contact Gender":"Pin (Male)","Shell Style":"In-Line","RoHS":"No"...
1647 Bytes - 15:37:52, 14 November 2024
Amphenol.com/MS3476W14-4PW-LC
{"Contact Classification":"4Signal","Strain Relief":"No","Number of Terminals":"4","Family":"MS3476","Voltage Rating":"600VAC","Gender":"PL","Body Orientation":"Straight","Product Height (mm)":"Not Required(mm)","Rad Hardened":"No","Contact Gender":"PIN","Mounting Style":"Cable","Number of Ports":"1(Port)","Operating Temp Range":"-65C to 200C","Product Depth (mm)":"Not Required(mm)","Product Diameter (mm)":"30.04(mm)","Termination Method":"Crimp","Shell Size / Insert Arrangement":"14-4","Number of Contacts"...
1670 Bytes - 15:37:52, 14 November 2024
Amphenol_spectra_strip/MS3476W14-4PW-LC
{"Contact Classification":"4Signal","Strain Relief":"No","Number of Terminals":"4","Family":"MS3476","Voltage Rating":"600VAC","Gender":"PL","Body Orientation":"Straight","Product Height (mm)":"Not Required(mm)","Rad Hardened":"No","Contact Gender":"PIN","Mounting Style":"Cable","Number of Ports":"1(Port)","Operating Temp Range":"-65C to 200C","Product Depth (mm)":"Not Required(mm)","Product Diameter (mm)":"30.04(mm)","Termination Method":"Crimp","Shell Size / Insert Arrangement":"14-4","Number of Contacts"...
1620 Bytes - 15:37:52, 14 November 2024
Deutsch.net/MS3476W14-4PW-LC
804 Bytes - 15:37:52, 14 November 2024
Deutsch_uk/MS3476W14-4PW-LC
{"Contact Classification":"4Signal","Type":"Circular","Current Rating (Max)":"23(A)","Product Height (mm)":"Not Required(mm)","Contact Plating":"Gold","Termination Method":"Crimp","Shell Size / Insert Arrangement":"14-4","Strain Relief":"No","Voltage Rating":"850VDC/600VAC","Gender":"PL","Body Orientation":"Straight","Contact Gender":"PIN","Number of Ports":"1(Port)","Operating Temp Range":"-55C to 175C","Product Diameter (mm)":"30.04(mm)","Family":"MS","Number of Terminals":"4","Mounting Style":"Cable","Ra...
1751 Bytes - 15:37:52, 14 November 2024
Souriau.com/MS3476W14-4PW-LC
{"Contact Classification":"4Signal","Type":"Circular","Current Rating (Max)":"23/Contact(A)","Product Height (mm)":"Not Required(mm)","Contact Plating":"Gold Over Nickel","Termination Method":"Crimp","Shell Size / Insert Arrangement":"14-4","Strain Relief":"No","Shell Plating":"Cadmium","Gender":"PL","Body Orientation":"Straight","Contact Gender":"PIN","Number of Ports":"1(Port)","Operating Temp Range":"-55C to 175C","Product Diameter (mm)":"29.75(mm)","Family":"MS3476W","Number of Terminals":"4","Mounting ...
1689 Bytes - 15:37:52, 14 November 2024
Te.com/MS3476W14-4PW-LC
{"Category":"Connectors, Interconnects","Packaging":"Bulk","Contact Size":"12","Ingress Protection":"Environment Resistant","Mounting Type":"Free Hanging (In-Line)","Family":"Circular Connectors - Housings","Series":"Military, MIL-C-26482 G Series II, AFD","Orientation":"W","Shell Size - Insert":"14-4","Connector Type":"Plug for Male Contacts","Shell Material, Finish":"Aluminum, Olive Drab Cadmium Plated","Number of Positions":"4","Note":"Contacts Not Provided","Datasheets":"AFD MIL-C-26482 Series, 2 MIL-C-...
1912 Bytes - 15:37:52, 14 November 2024
