1713B-page 42 = 0C to +70C Commercial = -40C to+85C Industrial = Standard packaging (tray) = Tape and Reel(1) Examples: a) b) c) d) e) f) g) h) USB2534-1080AEN, Commercial Temp 36-pin SQFN Pkg., Tray USB2534-1050AEN, Commercial Temp 36-pin SQFN Pkg., Tray USB2534-1080AEN-TR, Commercial Temp 36-pin SQFN Pkg., Tape & Reel USB2534-1050AEN-TR, Commercial Temp 36-pin SQFN Pkg., Tape & Reel USB2534i-1080AEN, Industrial Temp 36-pin SQFN Pkg., Tray USB2534i-1050AEN-TR, Industrial Temp 36-pin SQFN Pkg., Tray USB2534i-1080AEN-TR, Industrial Temp 36-pin SQFN Pkg., Tape & Reel USB2534i-1050AEN-TR, Industrial Temp 36-pin SQFN Pkg., Tape & Reel Note 1: Tape and Reel identifier only appears in the catalog part number description. This identifier is used for ordering purposes and is not printed on the device package. Check with your Microchip Sales Office for package availability with the Tape and Reel option. Reel size is 4,000. 2012 - 2019 Microchip Technology Inc. USB2534 PREVIOUS VERSION ORDERING INFORMATION

70C) -- Industrial temperature range support (-40C to 85C) SMSC USB2534 Revision 1.0 (06-17-13) DATASHEET USB 2.0 Hi-Speed 4-Port Hub Controller Datasheet Order Number(s): ORDER NUMBER TEMPERATURE RANGE PACKAGE TYPE USB2534-1080AEN 0C to +70C 36-pin SQFN USB2534-1080AEN-TR 0C to +70C 36-pin SQFN (Tape & Reel) USB2534i-1080AEN -40C to +85C 36-pin SQFN USB2534i-1080AENTR -40C to +85C 36-pin SQFN (Tape & Reel) This product meets the halogen maximum concentration values per IEC61249-2-21 For RoHS compliance and environmental information, please visit www.smsc.com/rohs Please contact your SMSC sales representative for additional documentation related to this product such as application notes, anomaly sheets, and design guidelines. The table above represents valid part numbers at the time of printing and may not represent parts that are currently available. For the latest list of valid ordering numbers for this product, please contact the nearest sales office. Copyright (c) 2013 SMSC or its subsidiari

URE RANGE PACKAGE TYPE 0C to +70C 36-pin SQFN 0C to +70C 36-pin SQFN (Tape & Reel) -40C to +85C 36-pin SQFN -40C to +85C 36-pin SQFN (Tape & Reel) USB2534-1080AEN (Battery Charging disabled by default) USB2534-1050AEN (Battery Charging enabled by default) USB2534-1080AEN-TR (Battery Charging disabled by default) USB2534-1050AEN-TR (Battery Charging enabled by default) USB2534i-1080AEN (Battery Charging disabled by default) USB2534i-1050AEN (Battery Charging enabled by default) USB2534i-1080AEN-TR (Battery Charging disabled by default) USB2534i-1050AEN-TR (Battery Charging enabled by default) This product meets the halogen maximum concentration values per IEC61249-2-21 The table above represents valid part numbers at the time of printing and may not represent parts that are currently available. For the latest list of valid ordering numbers for this product, please contact the nearest sales office. TO OUR VALUED CUSTOMERS It is our intention to provide our valued customers with the best documentati
