IPP220N25NFD DataSheet Rev.2.0 Final PowerManagement&Multimarket OptiMOSTMFDPower-Transistor,250V IPP220N25NFD 1Description TO-220-3 tab Features *N-channel,normallevel *FastDiode(FD)withreducedQrr *Optimizedforhardcommutationruggedness *Verylowon-resistanceRDS(on) *175Coperatingtemperature *Pb-freeleadplating;RoHScompliant *QualifiedaccordingtoJEDEC1)fortargetapplication *Halogen-freeaccordingtoIEC61249-2-21 Drain Pin 2, tab Table1KeyPerformanceParameters Parameter Value Unit VDS 250 V RDS(on),max 22 m ID 61 A Type/OrderingCode Package IPP220N25NFD PG-TO220-3 1) Gate Pin 1 Source Pin 3 Marking 220N25NF RelatedLinks - J-STD20 and JESD22 Final Data Sheet 2 Rev.2.0,2014-02-06 OptiMOSTMFDPower-Transistor,250V IPP220N25NFD TableofContents Description . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2 Maximum ratings . . . . . . . . . . . . . . . . . . . . . .
