Product Datasheet Search Results:
14 Pages, 719 KB, Original- PSMN1R3-30YL,115
- Nexperia
- Trans MOSFET N-CH 30V 100A 5-Pin(4+Tab) LFPAK T/R
14 Pages, 216 KB, Original- PSMN1R3-30YL,115
- Nxp Semiconductors
- MOSFET N-CH 30V 100A LFPAK - PSMN1R3-30YL,115
Product Details Search Results:
Nexperia/PSMN1R3-30YL,115
{"Polarity":"N","Gate-Source Voltage (Max)":"20(V)","Channel Mode":"Enhancement","Operating Temperature Classification":"Military","Continuous Drain Current":"100(A)","Mounting":"Surface Mount","Rad Hardened":"No","Drain-Source On-Volt":"30(V)","Packaging":"Tape and Reel","Power Dissipation":"121(W)","Operating Temp Range":"-55C to 150C","Package Type":"LFPAK","Type":"Power MOSFET","Pin Count":"4 +Tab","Number of Elements":"1"}...
1415 Bytes - 17:16:27, 18 April 2025
Nxp.com/PSMN1R3-30YL,115
{"Category":"Discrete Semiconductor Products","FET Feature":"Logic Level Gate","Vgs(th) (Max) @ Id":"2.15V @ 1mA","Featured Product":"LFPAK Trench 6 MOSFETs","Package / Case":"SOT-1023, 4-LFPAK","Current - Continuous Drain (Id) @ 25\u00b0C":"100A (Tc)","Gate Charge (Qg) @ Vgs":"100nC @ 10V","Product Photos":"LFPAK2, SOT1023","Rds On (Max) @ Id, Vgs":"1.3 mOhm @ 15A, 10V","Datasheets":"PSMN1R3-30YL","FET Type":"MOSFET N-Channel, Metal Oxide","PCN Packaging":"Leader/Trailer Update 03/Apr/2015","Drain to Sourc...
1857 Bytes - 17:16:27, 18 April 2025
